Hex bolt D931/I4014 10.9 ZPL M10x40

Hexagon head bolt DIN 931 / ISO 4014 10.9 Steel Zinc plated M10 x 40
  • Availability: In Stock
  • Product number: 01251.010040
Availability: In Stock
€62.90
Description Specification Documents
Hexagon head bolt DIN 931 / ISO 4014 10.9 Steel Zinc plated M10 x 40

Specification

Description
Hex bolt D931/I4014 10.9 ZPL M10x40
Artnr.
01251.010040
Diameter numeric
10
Diameter
M10
Quality
10.9
Length
40
Size
M10 X 40
normalization
D931/I4014
Version
ELVZ
Thread length B1
26
Thread length B2
32
Thread length B3
45
head height
6,4
Spanner size
17(16)
Pitch
1.5
